Vehicle Guard · Model JVD-400 · Preliminary specification
Vehicle Jammer Detector
Selective jammer detection for cars, vans, hgvs, plant and high-value assets. Designed to detect abnormal in-band RF conditions rather than simply respond to every nearby RF transmitter.
Production image will be added when the prototype enclosure is complete.
Need dedicated satellite-navigation monitoring rather than combined vehicle coverage? See the GPS Jammer Detector range.
Design specification
Vehicle Guard Model JVD-400
Model
JVD-400
RF coverage
GNSS L1/E1 + selected UK cellular downlink bands
Detection
Band-selective RF power / abnormal interference event detection
Alarm
GNSS / cellular service alarm
Logging
RTC timestamped event log
Power
12 V vehicle / rechargeable
RF mode
Passive receive-only
Planned production features
- GNSS plus cellular monitoring
- Simultaneous multi-band event detection
- Configurable installation thresholds
- Affected service, time, duration and peak logging
- Passive receive-only
Band-selective detection: ordinary broadband RF detectors can alarm on legitimate phones, radios and wireless devices. Vehicle Guard restricts detection to the relevant service bands. An alarm indicates an abnormal in-band RF condition; further investigation may be needed to establish the source and intent.
